Our Pulses Color Sorter Machine provides accurate optical sorting for a wide variety of pulses. The advanced AI technology detects color differences, foreign materials, damaged seeds, and impurities to ensure premium-grade products.
Ideal for pulse processing plants, exporters, wholesalers, and food manufacturers.
Features
- AI intelligent sorting
- High-resolution cameras
- Fast processing speed
- High rejection accuracy
- User-friendly operation
- Energy-saving design
STRIVES TO PROVIDE INTELLIGENT SORTING SOLUTIONS FOR GLOBAL PULSES PROCESSING INDUTRY
Inheriting 15+ years of professional quality accumulation in DIVINE, 16 core technologies are blessed, stronger applicability, and more durable. One machine has multiple sorting models, which can easily control the sorting needs of different colors, yellow, whites and other process points, and perfectly create cost-effective sorting of popular items. It is your quality choice!
Inheriting the excellant characteristics of Ri products, the intelligent technology continues to evolve the uniform feeding technology, intelligent early warning technology and other comprehensive upgrades, while more intelligent the sorting and protection algorithm is continuously optimized, the sorting of yellow and white is more accurate, the finished product is better by-products are more valuable, excellent choice.
MINI SIZE MULTIFUNCTIONAL
MINI SIZE HIGH-PERFORMANCE-STABLE-STRUCTURE-HIGH-EFFICIENCY
- Ultra-high integration for greater efficiency
- One-piece molding, compact structure, convenient and practical
Core Specification
Intelligent Image Recognition
The new Hi-Vision multidimensional feature recognition technology continuously perceives, improves and iterates data, achieving limitless recognition capabilities.
Target Position 3.0 Algorithm
Based on material trajectory, posture, position, speed and other information, it accurately matches the best hitting method to ensure a 100% hit rate.
Super Alloy UFH Ejector
Independently developed with national patents, the UFH ejector boasts low energy consumption, high wear and high temperature resistance and longtime durability.
Adaptive Light Source System
'Divine Tech' upgraded lighting system uses high brightness, high-penetration light sources to intelligently match sorting needs, improving penetration in dark areas for better sorting accuracy.
S-Class Vision System
Customized ultra-high-transmission optics with multi-frame synthetic noise reduction and true color reproduction for accurate identification of subtle color defects.
All Things Connected
Real-time online on the Divine Tech cloud platform, with remote interconnection for control, maintenance, early warning, upgrading, operation and maintenance data, and intelligent online operation inspection.
Technical Specifications
| Model | Throughput (T/H) | Accuracy | Voltage | Power (kW) | Weight (kg) | Dimension (mm) |
|---|---|---|---|---|---|---|
| RI 1 | 1-2 | >99.99% | 220/50 | 0.5 | 280 | 898*1504*1361 |
| RI 2 | 2-4 | >99.99% | 220/50 | 0.75 | 355 | 1088*1504*1361 |
| RI 3 | 3-6 | >99.99% | 220/50 | 1.0 | 500 | 1474*1504*1361 |
| RI 4 | 4-8 | >99.99% | 220/50 | 1.5 | 650 | 1786*1523*1781 |
| RI 5 | 5-10 | >99.99% | 220/50 | 1.5 | 850 | 2056*1523*1781 |
| RI 6 | 6-12 | >99.99% | 220/50 | 1.9 | 1050 | 2338*1523*1781 |
| RI 7 | 7-14 | >99.99% | 220/50 | 2.25 | 1250 | 2620*1523*1781 |
| RI 8 | 8-16 | >99.99% | 220/50 | 2.5 | 1650 | 2914*1523*1781 |
| RI 10 | 10-20 | >99.99% | 220/50 | 3.0 | 1850 | 3490*1523*1781 |
Note: The above parameters will vary according to the impurity content of raw materials.
Applications
Green Gram
Black Gram
Red Gram
Bengal Gram
Horse Gram
Cowpea
Kidney Beans
Peas
Benefits
- Removes impurities
- Consistent product quality
- Higher export standards
- Less manual sorting
- Better production efficiency
