The Dal Color Sorter Machine delivers precise sorting of pulses by removing damaged, broken, infected, immature, and discolored dal. Equipped with intelligent vision technology, the machine guarantees premium quality products for domestic and export markets.
Suitable for all major varieties of dal, this machine improves efficiency and minimizes manual inspection.
Features
- High-speed sorting system
- Intelligent image processing
- AI-powered optical inspection
- High-resolution CCD cameras
- Easy-to-use control system
- Low maintenance
STRIVES TO PROVIDE INTELLIGENT SORTING SOLUTIONS FOR GLOBAL DAL PROCESSING INDUTRY
Inheriting 15+ years of professional quality accumulation in DIVINE, 16 core technologies are blessed, stronger applicability, and more durable. One machine has multiple sorting models, which can easily control the sorting needs of different colors, yellow, whites and other process points, and perfectly create cost-effective sorting of popular items. It is your quality choice!
Inheriting the excellant characteristics of Ri products, the intelligent technology continues to evolve the uniform feeding technology, intelligent early warning technology and other comprehensive upgrades, while more intelligent the sorting and protection algorithm is continuously optimized, the sorting of yellow and white is more accurate, the finished product is better by-products are more valuable, excellent choice.
MINI SIZE MULTIFUNCTIONAL
MINI SIZE HIGH-PERFORMANCE-STABLE-STRUCTURE-HIGH-EFFICIENCY
- Ultra-high integration for greater efficiency
- One-piece molding, compact structure, convenient and practical
Core Specification
Intelligent Image Recognition
The new Hi-Vision multidimensional feature recognition technology continuously perceives, improves and iterates data, achieving limitless recognition capabilities.
Target Position 3.0 Algorithm
Based on material trajectory, posture, position, speed and other information, it accurately matches the best hitting method to ensure a 100% hit rate.
Super Alloy UFH Ejector
Independently developed with national patents, the UFH ejector boasts low energy consumption, high wear and high temperature resistance and longtime durability.
Adaptive Light Source System
'Divine Tech' upgraded lighting system uses high brightness, high-penetration light sources to intelligently match sorting needs, improving penetration in dark areas for better sorting accuracy.
S-Class Vision System
Customized ultra-high-transmission optics with multi-frame synthetic noise reduction and true color reproduction for accurate identification of subtle color defects.
All Things Connected
Real-time online on the Divine Tech cloud platform, with remote interconnection for control, maintenance, early warning, upgrading, operation and maintenance data, and intelligent online operation inspection.
Technical Specifications
| Model | Throughput (T/H) | Accuracy | Voltage | Power (kW) | Weight (kg) | Dimension (mm) |
|---|---|---|---|---|---|---|
| RI 1 | 1-2 | >99.99% | 220/50 | 0.5 | 280 | 898*1504*1361 |
| RI 2 | 2-4 | >99.99% | 220/50 | 0.75 | 355 | 1088*1504*1361 |
| RI 3 | 3-6 | >99.99% | 220/50 | 1.0 | 500 | 1474*1504*1361 |
| RI 4 | 4-8 | >99.99% | 220/50 | 1.5 | 650 | 1786*1523*1781 |
| RI 5 | 5-10 | >99.99% | 220/50 | 1.5 | 850 | 2056*1523*1781 |
| RI 6 | 6-12 | >99.99% | 220/50 | 1.9 | 1050 | 2338*1523*1781 |
| RI 7 | 7-14 | >99.99% | 220/50 | 2.25 | 1250 | 2620*1523*1781 |
| RI 8 | 8-16 | >99.99% | 220/50 | 2.5 | 1650 | 2914*1523*1781 |
| RI 10 | 10-20 | >99.99% | 220/50 | 3.0 | 1850 | 3490*1523*1781 |
Note: The above parameters will vary according to the impurity content of raw materials.
Applications
Toor Dal
Urad Dal
Moong Dal
Chana Dal
Masoor Dal
Green Gram
Black Gram
Benefits
- Higher sorting accuracy
- Better product quality
- Increased production capacity
- Reduced labor costs
- Improved profitability
